Product Overview
The CGS Tool 2001-S has a diameter of 1/8”, 2 flute solid carbide square end mill, made for maximum material removal and smooth surface work in aluminum, non ferrous metals, and plastics. The tool comes under the Ferocious Series, and it’s aimed at machinists who want high performance at really extreme feed rates.
Made with premium sub micro grain carbide, the 2001-S comes with a 55° high helix that helps with chip evacuation, keeps cutting forces lower, and delivers a great surface finish. The polished cutting edges plus a free cutting geometry, means it resists built up edges, while still keeping an excellent tool life even when you’re running high speed CNC jobs.
Tool Specifications:
- Diameter: 1/8”
- Shank: 1/8”
- Length of Cut (LOC): 1/2”
- Overall Length (OAL): 1-1/2”
- Flutes: 2 - Square End
- Material: Solid Micro-Grain Carbide
- Coating: ZrN
- Series: CGS Ferocious
- Part No: 2001-S
Key Performance Features:
- 2-Flute, 55° High Helix design for aluminum and non-ferrous machining
- Ultra-smooth polished land for superior surface finish
- Capable of extreme RPM and feed rates
- Excellent chip evacuation and edge strength
- Ideal for roughing, slotting, and contouring applications
- Reduced neck & Weldon flats available upon request
- ZrN coating provides extended tool life and cleaner cuts in non-ferrous materials
