Product Overview
Precise chip clearance at 7/64" diameter — the CGS Tool 220-1094 is a 2-flute square end mill from the 220 Series built for small slotting, profiling, pocketing, and light stock removal.
The compact 2-flute geometry gives useful chip space, and the square end profile keeps bottoms and walls accurate. Uncoated carbide handles mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites.
Tool Specifications:
- Diameter: 7/64"
- Shank: 1/8"
- Length of Cut (LOC): 5/32"
- Overall Length (OAL): 1-1/2"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Helix: 30°
- Design: Single End
- Series: CGS 220 Series
- Part No: 220-1094
Key Performance Features:
- 2-flute square end design provides strong chip clearance
- 30° helix supports smooth cutting and controlled chip movement
- Solid carbide construction provides rigidity and cutting accuracy
- Uncoated finish suited for flexible general-purpose machining
- Compact size supports detailed slotting and profiling work
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites
- Built for small-feature milling, pocketing, and light stock removal
