Product Overview
Two working ends at 3/4" diameter, the CGS Tool 440-7500-ALTiN basically brings that whole value into the 440 Series— it ’s a 4-flute square end mill that is meant for stable milling and dependable stock removals. ALTiN coating helps protect the cutting edge during heat-heavy operations, and the square end profile keeps the bottoms clean and the walls pretty accurate too, you know.
Also it has double-end construction, plus solid carbide strength, so it ends up being a reliable pick across mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics and composites.
Tool Specifications:
- Diameter: 3/4"
- Shank: 3/4"
- Length of Cut (LOC): 1-1/8"
- Overall Length (OAL): 2-1/2"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: ALTiN
- Helix: 30°
- Design: Double End
- Series: CGS 440 Series
- Part No: 440-7500-ALTiN
Key Performance Features:
- 4-flute square end design for stable milling and clean cutting
- Double-end construction provides two usable cutting ends
- ALTiN coating helps improve heat resistance and edge life
- 30° helix supports smooth cutting and balanced chip evacuation
- Solid carbide construction provides rigidity and wear resistance
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites
- Built for slotting, profiling, pocketing, and general-purpose milling
