Product Overview
The CGS Tool 820-1000-ALTiN is a 1" diameter 2-flute solid carbide square end mill built for shops that need real reach without giving up rigidity. It's part of the 820 Series, CGS Tool's long-reach general-purpose line, and it earns its keep on deeper slots, extended profiles, plunge work, and side wall milling where a shorter tool simply can't get there.
The ALTiN coating is what carries this one through the tougher cuts — it holds up against heat buildup and wear as the 3" length of cut works its way through material that would wear down an uncoated edge fast. At 6" overall, the 820-1000-ALTiN gives CNC shops the depth they need across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 1"
- Shank: 1"
- Length of Cut (LOC): 3"
- Overall Length (OAL): 6"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: ALTiN
- Series: CGS 820 Series
- Part No: 820-1000-ALTiN
Key Performance Features:
- 2-flute square end built for long-reach milling work
- 3" LOC opens up access to deeper features
- ALTiN coating pushes back against heat and wear
- 6" OAL gets into features shorter tools can't reach
- Handles slotting, profiling, plunge cuts, and side wall passes
- Works across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
