Product Overview
The CGS Tool 822-1000 is a 1" diameter 2-flute solid carbide ball end mill from the 822 Series, built for larger contour and profile applications where deeper rounded surfaces and broad pocket blending matter. Its .500" radius is sized for real reach on bigger parts.
Built on the same precision CNC equipment as CGS Tool's other general-purpose lines, it holds a 30° helix matched to its 3" length of cut and 6" overall length for deep, long-reach finishing work. Uncoated and rated across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, it's a strong choice for large radius shaping.
Tool Specifications:
- Diameter: 1"
- Shank: 1"
- Length of Cut (LOC): 3"
- Overall Length (OAL): 6"
- Flutes: 2 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .500"
- Series: CGS General Purpose (822 Series)
- Part No: 822-1000
Key Performance Features:
- 2-Flute ball end design for large profile and contour work
- .500" radius matched to diameter for broad rounded surfaces
- Extended LOC gives deeper cutting reach
- 30° helix with precision-ground cutting edges
- Effective across mild steels, stainless, cast iron, and titanium
- Also suited to non-ferrous metals, plastics, and composites
