Product Overview
Deeper side walls and extended profiles need a tool that can reach them, and the 840-4375 provides that at 7/16" diameter. This 4-flute square end mill carries a 3" length of cut and 6" overall length, built for applications where a shorter cutter simply won't reach.
Built with a 30° helix and uncoated solid carbide body, this 840 Series tool gives steady stock removal in everyday machining work. It's a dependable option for slotting, profiling, plunge cutting, and side wall milling across mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 7/16"
- Shank: 7/16"
- Length of Cut (LOC): 3"
- Overall Length (OAL): 6"
- Flutes: 4 Flute
- End Style: Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: 840 Series
- Part No: 840-4375
Key Performance Features:
- 4-flute square end built for long-reach milling
- 3" length of cut gives extended cutting depth
- 6" overall length supports access into deeper features
- 30° helix supports smooth, controlled cutting
- Handles slotting, profiling, plunging, and side wall milling
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
