Product Overview
Bigger work needs real reach, and the 840-7500 of delivers it, at a 3/4" diameter. This 4-flute square end mill is made for deeper grooves and longer shapes, plus plunge cutting, taller side walls, and flatter bottom jobs where extension actually matters.With a 3" length of cut and a 6" overall length, this 840 Series cutter gives that extended cutting depth for larger milling tasks. It comes with a 30° helix, and an uncoated carbide build, so you get dependable square-end results across a bunch of usual materials.
Tool Specifications:
- Diameter: 3/4"
- Shank: 3/4"
- Length of Cut (LOC): 3"
- Overall Length (OAL): 6"
- Flutes: 4 Flute
- End Style: Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: 840 Series
- Part No: 840-7500
Key Performance Features:
- 4-flute square end built for long-reach milling
- 3" length of cut gives extended cutting depth
- 6" overall length supports deeper machining access
- 30° helix supports smooth chip movement
- Handles slots, profiles, plunge cuts, and side wall milling
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
