Product Overview
The CGS Tool BN5303-S is a 3/16" diameter 3-flute solid carbide ball end mill from the Ferocious 3x BN5300 Series, sized for aluminum and non-ferrous work where a rounded profile and quick chip clearing need to come together in a small cutter. It's built specifically for that job rather than as a general do-everything tool.
Its ZrN coating suits aluminum, copper, brass, plastics, and composites particularly well, and the Ferocious 3x flute design combined with wiper end geometry and variable helix and pitch is engineered to reduce chatter at higher feed rates. It's a tool that stays clean under strong stock removal.
Tool Specifications:
- Diameter: 3/16"
- Shank: 3/16"
- Length of Cut (LOC): 5/8"
- Overall Length (OAL): 2"
- Flutes: 3 - Ball End
- Material: Solid Carbide
- Coating: ZrN
- Radius: .0938"
- Series: BN5300 / Ferocious 3x Series
- Part No: BN5303-S
Key Performance Features:
- 3-Flute ball end design for non-ferrous profile work
- ZrN coating matched to cleaner aluminum machining
- Variable helix and pitch reduce chatter and harmonics
- Wiper end geometry improves finish quality
- Effective across aluminum, copper, and brass
- Also suited to plastics and composites
