Product Overview
Larger milling jobs still need reliable corner support, and the CR123-1000.020-ALTiN provides it at a full 1" diameter. This 2-flute corner radius end mill carries a .020" radius, supporting the cutting edge while keeping the finished profile clean and controlled.
ALTiN coating helps improve heat and wear resistance during more demanding machining conditions. With a 1-1/2" length of cut, 4" overall length, and 30° helix, this CR123 Series cutter is useful for slotting, profiling, shoulder work, and side wall milling.
Tool Specifications:
- Diameter: 1"
- Shank: 1"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 2 Flute
- End Style: Corner Radius
- Material: Solid Carbide
- Coating: ALTiN
- Radius: .020"
- Series: CR123 Series
- Part No: CR123-1000.020-ALTiN
Key Performance Features:
- 2-flute corner radius design built for larger general-purpose milling
- .020" radius helps reduce sharp-corner wear
- ALTiN coating supports better heat and wear resistance
- 30° helix gives smooth cutting control
- Handles slotting, profiling, shoulder work, and side wall milling
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
