Product Overview
The CGS Tool CR123-7500.125-ALTiN is a 3/4" diameter 2-flute solid carbide corner radius end mill built for larger general-purpose milling, where a .125" corner radius gives strong edge support in heavier cuts.
The ALTiN coating adds heat and wear resistance under demanding machining conditions, and with a 1-1/2" length of cut, 4" overall length, and 30° helix, this CR123 Series cutter is useful for slotting, profiling, shoulder work, and side wall milling across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 3/4"
- Shank: 3/4"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 2 - Corner Radius
- Material: Solid Carbide
- Coating: ALTiN
- Radius: .125"
- Series: CGS CR123 Series
- Part No: CR123-7500.125-ALTiN
Key Performance Features:
- Larger general-purpose milling handled by a 2-flute corner radius design
- .125" radius improves cutting-edge strength
- ALTiN coating supports better heat and wear resistance
- 30° helix gives smooth cutting control
- Suited to slotting, profiling, shoulder work, and side wall milling
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
