Product Overview
The CGS Tool 120-1094-ALTiN is a 7/64" diameter 2-flute solid carbide square end mill from the 120 Series, sized for small, controlled milling where clean slots and sharp flat-bottom details matter in tighter areas. It's built for detail-scale precision.
Built on the same precision CNC equipment as CGS Tool's other general-purpose lines, it holds a 30° helix and an ALTiN coating matched to extra protection against heat and wear over a bright uncoated tool. Rated across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, it's a dependable choice.
Tool Specifications:
- Diameter: 7/64"
- Shank: 1/8"
- Length of Cut (LOC): 3/8"
- Overall Length (OAL): 1-1/2"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: ALTiN
- Radius: No
- Series: CGS General Purpose (120 Series)
- Part No: 120-1094-ALTiN
Key Performance Features:
- 2-Flute square end design for small milling applications
- ALTiN coating matched to diameter for wear resistance
- 30° helix with precision-ground cutting edges
- Compact sizing gives better control in fine features
- Effective across mild steels, stainless, cast iron, and titanium
- Also suited to non-ferrous metals, plastics, and composites
