Product Overview
Accurate side-wall control at 13/32" diameter — the CGS Tool 140-4062 is a 4-flute square end mill from the 140 Series built for stable cutting in slotting, profiling, and pocketing.
The 4-flute design gives strength and stability, and the square end profile keeps side-wall control precise. Uncoated carbide handles mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites.
Tool Specifications:
- Diameter: 13/32"
- Shank: 7/16"
- Length of Cut (LOC): 1"
- Overall Length (OAL): 2-3/4"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Helix: 30°
- Design: Single End
- Series: CGS 140 Series
- Part No: 140-4062
Key Performance Features:
- 4-flute square end design for stable milling and clean stock removal
- 30° helix supports smooth cutting and controlled chip movement
- Solid carbide construction provides rigidity and wear resistance
- Uncoated finish suited for general-purpose machining flexibility
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites
- Built for slotting, profiling, pocketing, plunge milling, and side-wall milling
- Strong option for shops needing a reliable 13/32" carbide end mill
