Product Overview
General-purpose milling with extra tool life, that's the value of the 440-4062 at .4062" diameter. This 4-flute square end mill uses a double-end design, useful where clean square-end cutting and added usable tool value are both needed.
With a 5/8" length of cut and 2-3/4" overall length, this 440 Series cutter gives steady control in slots, profiles, plunge cuts, and side wall applications. Its uncoated solid carbide construction makes it practical for everyday CNC milling.
Tool Specifications:
- Diameter: .4062"
- Shank: 7/16"
- Length of Cut (LOC): 5/8"
- Overall Length (OAL): 2-3/4"
- Flutes: 4 Flute
- End Style: Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: 440 Series
- Part No: 440-4062
Key Performance Features:
- 4-flute square end built for general-purpose milling
- Double-end design gives use from both cutting ends
- .4062" diameter supports controlled stock removal
- 30° helix supports smooth chip movement
- Handles slotting, profiling, plunging, and side wall milling
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
