Product Overview
Smooth ball-end profile work with two usable cutting edges, that's the 422-5000-ALTiN at 1/2" diameter. This 2-flute ball end mill uses a double-end design, made for profile work, contour milling, surface blending, and rounded pocket details.
ALTiN coating gives this cutter added heat and wear resistance, making it useful in tougher or longer-running applications. With its .250" radius and 30° helix, the 422-5000-ALTiN gives reliable performance across a wide range of general-purpose materials.
Tool Specifications:
- Diameter: 1/2"
- Shank: 1/2"
- Length of Cut (LOC): 5/8"
- Overall Length (OAL): 3"
- Flutes: 2 Flute
- End Style: Ball End
- Material: Solid Carbide
- Coating: ALTiN
- Radius: .250"
- Series: 422 Series
- Part No: 422-5000-ALTiN
Key Performance Features:
- 2-flute ball end built for contour and profile milling
- Double-end design gives use from both cutting ends
- ALTiN coating improves heat and wear resistance
- .250" radius supports smooth, rounded surface work
- Handles finishing, blending, and curved pocket machining
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
