Product Overview
The CGS Tool 442-1094 is a 7/64" diameter 4-flute solid carbide ball end mill with a double-end design, built for fine contour work where small rounded details need careful, deliberate cutting control.
Its .0547" radius gives a clean ball-end form for small curved surfaces, and with usable cutting edges on both ends, this 442 Series tool gives practical value for general-purpose CNC milling.
Tool Specifications:
- Diameter: 7/64"
- Shank: 1/8"
- Length of Cut (LOC): 5/32"
- Overall Length (OAL): 1-1/2"
- Flutes: 4 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .0547"
- Series: CGS 442 Series
- Part No: 442-1094
Key Performance Features:
- Compact contour milling handled by a 4-flute ball end design
- Double-end construction gives use from both cutting ends
- .0547" radius supports small rounded feature work
- 30° helix helps maintain controlled chip movement
- Suited to finishing, blending, and small pocket machining
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
