Product Overview
Broader rounded surfaces need a bigger ball end tool, and the 442-6250 provides one at 5/8" diameter. This 4-flute ball end mill carries a .3125" radius and a double-end design, giving shops two usable cutting edges for contour milling, pocket blending, and finishing work.
With a 30° helix and uncoated carbide body, this 442 Series tool delivers reliable general-purpose performance without asking for special setup. Broader rounded surfaces, curved profiles, and blending passes are all well within reach across mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 5/8"
- Shank: 5/8"
- Length of Cut (LOC): 3/4"
- Overall Length (OAL): 4"
- Flutes: 4 Flute
- End Style: Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .3125"
- Series: 442 Series
- Part No: 442-6250
Key Performance Features:
- 4-flute ball end built for larger contour milling
- Double-end design gives use from both cutting ends
- .3125" radius supports smooth, rounded surface work
- 30° helix supports steady, controlled chip movement
- Suited to finishing, blending, and profile applications
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
