Product Overview
The CGS Tool 5301 is a 1/8" diameter 3-flute solid carbide square end mill from the Ferocious 3x 5300 Series, sized for compact aluminum and non-ferrous work where clean chip flow and fine surface finish matter even at small diameter.
The Ferocious 3x geometry uses variable helix, variable pitch, and wiper end design to reduce chatter and improve finish quality, and with a 1/2" length of cut and 1-1/2" overall length, this cutter is useful for compact non-ferrous milling work.
Tool Specifications:
- Diameter: 1/8"
- Shank: 1/8"
- Length of Cut (LOC): 1/2"
- Overall Length (OAL): 1-1/2"
- Flutes: 3 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS Ferocious 3x 5300 Series
- Part No: 5301
Key Performance Features:
- Aluminum and non-ferrous milling handled by a 3-flute square end design
- 1/8" diameter supports compact machining features
- Wiper end geometry improves surface finish
- Variable helix and variable pitch reduce chatter and harmonics
- Built for strong feeds and efficient material removal
- Ideal for aluminum, copper, brass, non-ferrous metals, plastics, and composites
